108W single light 108W 144W RGB/RGBW LED Polarized Washer

108W single light LED polarized wall washer,  108W/144W color changing RGB/ RGBW dmx512 LED polaration wall washer P65, AC100-240V/DC24V optional.

Description



Product features of the LED wall washer:

  1. Self-developed polarized optics can effectively improve the efficiency of light output. Anti-glare shading plate is optional.
  2. Equipped with CREE/OSRAM light source, with excellent lighting performance.
  3. Single light color, 3in1 RGB, 4in1 RGBW optional, support DMX512 control system. Automatic addressing, simple wiring makes the installation and maintenance of lamps more convenient and faster.
  4. Original structure design, internal cavity type heat dissipation, the overall appearance is refined, delicate and beautiful. Structural waterproof and no glue filling process, protection grade IP66
  5. 6063 aluminum alloy lamp body, SUS304 stainless steel screw, double movable brackets. surface with outdoor-grade electrostatic spraying, strong corrosion resistance and suitable for harsh outdoor environments.



Specification:

Input voltage: AC100-250V 50Hz / DC24V optional

Electrical safety level: Class I / Class III

LED light source: CREE/OSRAM

Driver: constant current driver

Control method: ON-OFF / DMX

Light angle: 18˚ + 45˚ polarized

Product weight: 4.70 KG

Product size: L 1000 * W 92 * H 107 mm



Article Nr. Power Voltage LED Quantity LED Type Light Color IP Rating
GYS-PSWW-108W 108W AC100-250V/DC24V optional 108 PCs OSRAM single light/DMX optional IP65
GYS-PSWW-108WA 108W AC100-250V/DC24V optional 54 PCs 3in1 RGB RGB DMX512 IP65
GYS-PSWW-108WB 108W AC100-250V/DC24V optional 54 PCs 4in1 RGBW RGBW DMX512 IP65
GYS-PSWW-144WA 144W AC100-250V/DC24V optional 72 PCs 3in1 RGB RGB DMX512 IP65
GYS-PSWW-144WB 144W AC100-250V/DC24V optional 72 PCs 4in1 RGBW RGBW DMX512 IP65



18W 24W 36W single light 36W 48W color changing dmx512 LED Linear Inground Light IP67

Installation and size:

108W single light 108W 144W RGB/RGBW LED Polarized Washer



*** LED wall washer with our self-developed polarized lens: can be made with our self-developed optical lens (18 degrees +45 degrees polarized), which has parallel and seamless up lighting, clean and comfortable vision. Equidistant arrangement, no dark areas and no overflow lighting. Suitable to be used for the accent lighting such as high walls, facades etc.





PS: the 18w with new desined lens 18˚ + 45˚  can replace the traditional 36W 10˚*60˚.



If there is any question, please feel free to contact us. Thank you very much.
