108W single light 108W 144W RGB/RGBW LED Polarized Washer
108W single light LED polarized wall washer, 108W/144W color changing RGB/ RGBW dmx512 LED polaration wall washer P65, AC100-240V/DC24V optional.
Product features of the LED wall washer:
- Self-developed polarized optics can effectively improve the efficiency of light output. Anti-glare shading plate is optional.
- Equipped with CREE/OSRAM light source, with excellent lighting performance.
- Single light color, 3in1 RGB, 4in1 RGBW optional, support DMX512 control system. Automatic addressing, simple wiring makes the installation and maintenance of lamps more convenient and faster.
- Original structure design, internal cavity type heat dissipation, the overall appearance is refined, delicate and beautiful. Structural waterproof and no glue filling process, protection grade IP66
- 6063 aluminum alloy lamp body, SUS304 stainless steel screw, double movable brackets. surface with outdoor-grade electrostatic spraying, strong corrosion resistance and suitable for harsh outdoor environments.
Input voltage: AC100-250V 50Hz / DC24V optional
Electrical safety level: Class I / Class III
LED light source: CREE/OSRAM
Driver: constant current driver
Control method: ON-OFF / DMX
Light angle: 18˚ + 45˚ polarized
Product weight: 4.70 KG
Product size: L 1000 * W 92 * H 107 mm
|Article Nr.||Power||Voltage||LED Quantity||LED Type||Light Color||IP Rating|
|GYS-PSWW-108W||108W||AC100-250V/DC24V optional||108 PCs||OSRAM||single light/DMX optional||IP65|
|GYS-PSWW-108WA||108W||AC100-250V/DC24V optional||54 PCs||3in1 RGB||RGB DMX512||IP65|
|GYS-PSWW-108WB||108W||AC100-250V/DC24V optional||54 PCs||4in1 RGBW||RGBW DMX512||IP65|
|GYS-PSWW-144WA||144W||AC100-250V/DC24V optional||72 PCs||3in1 RGB||RGB DMX512||IP65|
|GYS-PSWW-144WB||144W||AC100-250V/DC24V optional||72 PCs||4in1 RGBW||RGBW DMX512||IP65|
Installation and size:
*** LED wall washer with our self-developed polarized lens: can be made with our self-developed optical lens (18 degrees +45 degrees polarized), which has parallel and seamless up lighting, clean and comfortable vision. Equidistant arrangement, no dark areas and no overflow lighting. Suitable to be used for the accent lighting such as high walls, facades etc.
PS: the 18w with new desined lens 18˚ + 45˚ can replace the traditional 36W 10˚*60˚.
If there is any question, please feel free to contact us. Thank you very much.
